| Engine Engine type Bore x Stroke Displacement Valves Compression ratio Max Power Max Torque Fuel system Transmission Final drive Clutch Ignition type Starting system Lubrication Exhaust system Spark plug Battery Gear ratios | Liquid cooled, in-line 4 cylinder cross plane crankshaft, DOHC 79.0 x 50.9 mm (3.1 x 2.0 inches) 998cc 4 valves per cylinder 13.0:1 200.00 HP (146.0 kW) @ 13500 rpm 112.00 Nm (11.4 kgf-m or 82.6 ft.lbs) @ 11500 rpm Fuel Injection with YCC-T and YCC-I 6-speed O-ring chain Multiplate slipper clutch Transistor Controlled Ignition Electric starter Wet sump 1st: 2nd: 3rd: 4th: 5th: 6th: |
| Dimensions Frame type Rake/trail Overall length Overall width Overall height Wheelbase Seat height Ground clearance Wet weight Fuel capacity Color Suspension (front) Suspension (rear) Tyre (front) Tyre (rear) Brake (front) Brake (rear) | Aluminum Deltabox 24° 2055 mm (80.9 inches) 690 mm (27.2 inches) 1150 mm (45.3 inches) 1405mm (55.3 inches) 860 mm (33.9 inches) 130 mm (5.1 inches) 200.9 kg (443.0 pounds) 17.03 litres (4.50 gallons) Carbon Fiber Liquid Metal 43mm Öhlins electronic suspension inverted fork; 4.7-in travel Öhlins electronic suspension, piggyback reservoir, 4-way adjustable 120/70ZR17M/C 200/55ZR17M/C Dual 320mm hydraulic disc; 4-piston caliper, UBS ABS Single 220mm hydraulic disc; UBS ABS |
| Engine Engine type Bore x Stroke Displacement Valves Compression ratio Max Power Max Torque Fuel system Transmission Final drive Clutch Ignition type Starting system Lubrication Exhaust system Spark plug Battery Gear ratios | Liquid cooled, single cylinder, four-stroke, SOHC 78.0 x 59.1 mm (3.1 x 2.3 inches) 124.7cc 4 valves per cylinder 11.2:1 15.00 HP (10.9 kW) @ 9000 rpm 12.24 Nm (1.2 kgf-m or 9.0 ft.lbs) @ 8000 rpm Injection 6-speed Chain Wet, multiple-disc coil spring Transistor Controlled Ignition Electric starter Wet sump 1st: 2nd: 3rd: 4th: 5th: 6th: |
| Dimensions Frame type Rake/trail Overall length Overall width Overall height Wheelbase Seat height Ground clearance Weight Fuel capacity Color Suspension (front) Suspension (rear) Tyre (front) Tyre (rear) Brake (front) Brake (rear) | Steel deltabox 25° 2,015 mm (79.3 inches) 660 mm (26.0 inches) 970 mm (38.2 inches) 1,355 mm (53.3 inches) 818 mm (32.2 inches) 155 mm (6.1 inches) 140.0 kg (308.6 pounds) 11.50 litres (3.04 gallons) Red, grey, blue Telescopic forks Linked monoshock with spring preload adjustment 100/80-R17 130/70-R17 Single hydraulic 292mm discs, twin piston calipers Single hydrarulic 230mm disc, single piston caliper |
| Engine Engine type Bore x Stroke Displacement Valves Compression ratio Max Power Max Torque Fuel system Transmission Final drive Clutch Ignition type Starting system Lubrication Exhaust system Spark plug Battery Gear ratios | Liquid cooled, in-line 4 cylinder, DOHC 79.0 x 50.9 mm (3.1 x 2.0 inches) 998cc 4 valves per cylinder. Titanium intake valves 13.0:1 200.00 HP (146.0 kW) @ 13500 rpm 112.40 Nm (11.5 kgf-m or 82.9 ft.lbs) @ 11500 rpm Fuel Injection with YCC-T and YCC-I 6-speed O-ring chain Multiplate slipper clutch Transistor Controlled Ignition Electric starter Wet sump 1st: 2nd: 3rd: 4th: 5th: 6th: |
| Dimensions Frame type Rake/trail Overall length Overall width Overall height Wheelbase Seat height Ground clearance Wet weight Fuel capacity Color Suspension (front) Suspension (rear) Tyre (front) Tyre (rear) Brake (front) Brake (rear) | 24° 2,055 mm (80.9 inches) 691 mm (27.2 inches) 1,151 mm (45.3 inches) 1,405 mm (55.3 inches) 856 mm (33.7 inches) 130 mm (5.1 inches) 199.1 kg (439.0 pounds) 17.03 litres (4.50 gallons) 60th Anniversary Yellow, Team Yamaha Blue, Matte Gray 43mm KYB inverted fork; fully adjustable; 4.7- in travel KYB piggyback shock, 4-way adjustable; 4.7- in travel 120/70ZR17M/C 190/55ZR17 Dual 320mm hydraulic disc; four-piston caliper, UBS ABS Single 220mm hydraulic disc; Unified Brake System and ABS |
| Engine Engine type Bore x Stroke Displacement Valves Compression ratio Max Power Max Torque Fuel system Transmission Final drive Clutch Ignition type Starting system Lubrication Exhaust system Spark plug Battery Gear ratios | Liquid cooled, single cylinder, two-stroke, Reed-valve-inducted 47.5 x 47.8 mm (1.9 x 1.9 inches) 85cc 4 valves per cylinder 8.2:1 Carburettor. Keihin PWK 28 6-speed Chain Multi-plate wet CDI Electric starter Wet sump 1st: 2nd: 3rd: 4th: 5th: 6th: |
| Dimensions Frame type Rake/trail Overall length Overall width Overall height Wheelbase Seat height Ground clearance Weight Fuel capacity Color Suspension (front) Suspension (rear) Tyre (front) Tyre (rear) Brake (front) Brake (rear) | Single-backbone, semi-double-cradle frame 28° 1,821 mm (71.7 inches) 759 mm (29.9 inches) 1,125 mm (44.3 inches) 1,257 mm (49.5 inches) 841 mm (33.1 inches) 330 mm (13.0 inches) 71.2 kg (157.0 pounds) 4.92 litres (1.30 gallons) Team Yamaha Blue/White Inverted fork Single shock 70/100-R17 90/100-R14 Single hydraulic 220mm discs, twin piston calipers Single hydrarulic 190mm disc, single piston caliper |
| Engine Engine type Bore x Stroke Displacement Valves Compression ratio Max Power Max Torque Fuel system Transmission Final drive Clutch Ignition type Starting system Lubrication Exhaust system Spark plug Battery Gear ratios | Liquid cooled, single cylinder, four-stroke, DOHC 97.0 x 60.8 mm (3.8 x 2.4 inches) 449.7cc 4 valves (titanium) per cylinder 12.5:1 Keihin fuel injection, 44mm Wide-ratio constant-mesh 5-speed; multiplate wet clutch "O" ring chain Wet multi-disc Transistor Controlled Ignition Electric & kick starter Wet sump 1st: 2nd: 3rd: 4th: 5th: |
| Dimensions Frame type Rake/trail Overall length Overall width Overall height Wheelbase Seat height Ground clearance Weight Fuel capacity Color Suspension (front) Suspension (rear) Tyre (front) Tyre (rear) Brake (front) Brake (rear) | Aluminum Bilateral Beam frame 28° 2,174 mm (85.6 inches) 826 mm (32.5 inches) 1,290 mm (50.8 inches) 2,164 mm (85.2 inches) 965 mm (38.0 inches) 335 mm (13.2 inches) 118.8 kg (262.0 pounds) 7.57 litres (2.00 gallons) Team Yamaha Blue KYB spring-type fork; fully adjustable, 12.2-in wheel travel KYB single shock; fully adjustable, 12.5-in wheel travel 90/90-21 Dunlop AT81F 120/90-18 Dunlop AT81 Single 270mm hydraulic disc with twin piston caliper Single 245mm hydraulic disc with single piston caliper |
| Frame Grips Handlebars Stem Forks Bars Headset Cranks Sprocket BB Gearing Chain Pedals Seat Rims Spokes Hub (front) Hub (rear) Brakes Brake Lever Bottom Bracket Tyres Wight | Hand-welded 100% High-tensile Steel Velo mini grips, 110mm Stolen 5.70” TIG welded high-tensile steel Alloy front load, 30mm 1020 Hi-Ten Steel, tapered legs, one-piece steerer, 32mm offset Built in Standard 1 1/8″ threadless Stolen OE 1-piece CrMo, 92mm Stolen 25T YBN 410 Black Wellgo Mini PC Medium width seat/post combo Fiction Spartan, Alloy 16H (Single-wall) 16h unsealed, 3/8” Axle 16h Cassette type, 12mm axle, one-piece CrMo driver APSE alloy caliper brake APSE alloy with hinged clamp Unsealed American 12"x2.10″ front and rear 17.59kg/6.75lbs |
| Frame Grips Handlebars Stem Forks Bars Headset Cranks Sprocket BB Gearing Chain Pedals Seat Rims Spokes Hub (front) Hub (rear) Brakes Brake Lever Bottom Bracket Tyres Wight | 100% CrMo tubing, looptail rear end, retro dropouts Special edition ODI Mushroom II grips with SE donuts Big Honkin' CrMo, Width:29"; Rise:6"; Backsweep:10°; Upsweep1° Retro alloy top-load with engraved SE logo & lightweight cutouts Landing Gear; Material: Full CrMo Tange 1 1/8″ threadless SE 3-piece V-Ridge cranks with SE Star spider; Material: Full CrMo; 180mm arm length Alloy SE Racing 39T KMC S1 SE Racing Bear Traps SE Flyer seat with custom SE bottle opener brace 20″ 36H double wall aluminium rims 14 gauge with brass nipples Sealed bearings, forged aluminium shell, 36H, 3/8" CrMo axle Sealed bearings, forged aluminium shell, 36H, CrMo axle, 9T driver Tektro 930-AL V-Brake with slick cable Tektro 316A, 2-finger alloy Sealed bearing American type Vee Tire Co x SE Racing Cub, 26"x2.0" front and rear 30.1lbs/13.65kg |
| Engine Engine type Bore x Stroke Displacement Valves Compression ratio Max Power Max Torque Fuel system Transmission Final drive Clutch Ignition type Starting system Lubrication Exhaust system Spark plug Battery Gear ratios | Liquid cooled, single cylinder, four-stroke, DOHC 97.0 x 60.8 mm (3.8 x 2.4 inches) 449.7cc 4 valves per cylinder 12.5:1 Yamaha Fuel Injection (YFI), Keihin 44mm 5-speed Chain Wet multi-disc Transistor Controlled Ignition Electric starter Wet sump 1st: 2nd: 3rd: 4th: 5th: |
| Dimensions Frame type Rake/trail Overall length Overall width Overall height Wheelbase Seat height Ground clearance Weight Fuel capacity Color Suspension (front) Suspension (rear) Tyre (front) Tyre (rear) Brake (front) Brake (rear) | Aluminum Bilateral Beam frame 28° 2,174 mm (85.6 inches) 826 mm (32.5 inches) 1,290 mm (50.8 inches) 1,481 mm (58.3 inches) 975 mm (38.4 inches) 335 mm (13.2 inches) 111.1 kg (245.0 pounds) 7.57 litres (2.00 gallons) Team Yamaha Blue/White, 60th Anniversary Yellow KYB Speed-Sensitive System, inverted fork: fully adjustable Monoshock, adjustable preload and rebound damping 80/100-R21 120/80-R19 Single hydraulic 250mm discs, twin piston calipers Single hydrarulic 245mm disc, single piston caliper |
| Engine Engine type Bore x Stroke Displacement Valves Compression ratio Max Power Max Torque Fuel system Transmission Final drive Clutch Ignition type Starting system Lubrication Exhaust system Spark plug Battery Gear ratios | Liquid cooled, single cylinder, four-stroke, DOHC 97.0 x 60.8 mm (3.8 x 2.4 inches) 449.7cc 4 valves per cylinder 12.5:1 Yamaha Fuel Injection (YFI), Keihin 44mm 5-speed Chain Wet multi-disc Transistor Controlled Ignition Electric starter Wet sump 1st: 2nd: 3rd: 4th: 5th: |
| Dimensions Frame type Rake/trail Overall length Overall width Overall height Wheelbase Seat height Ground clearance Weight Fuel capacity Color Suspension (front) Suspension (rear) Tyre (front) Tyre (rear) Brake (front) Brake (rear) | Aluminum Bilateral Beam frame 28° 2,174 mm (85.6 inches) 826 mm (32.5 inches) 1,290 mm (50.8 inches) 1,481 mm (58.3 inches) 975 mm (38.4 inches) 335 mm (13.2 inches) 111.1 kg (245.0 pounds) 7.57 litres (2.00 gallons) Team Yamaha Blue/White, 60th Anniversary Yellow KYB Speed-Sensitive System, inverted fork: fully adjustable Monoshock, adjustable preload and rebound damping 80/100-R21 120/80-R19 Single hydraulic 250mm discs, twin piston calipers Single hydrarulic 245mm disc, single piston caliper |
| Engine Engine type Bore x Stroke Displacement Valves Compression ratio Max Power Max Torque Fuel system Transmission Final drive Clutch Ignition type Starting system Lubrication Exhaust system Spark plug Battery Gear ratios | Liquid cooled, single cylinder, two-stroke, reed-valve inducted 66.4 x 72.0 mm (2.6 x 2.8 inches) 249cc 13.5:1 Keihin PWK38S Constant-mesh 5-speed Chain Multi-plate wet CDI Electric starter Wet sump 1st: 2nd: 3rd: 4th: 5th: |
| Dimensions Frame type Rake/trail Overall length Overall width Overall height Wheelbase Seat height Ground clearance Weight Fuel capacity Color Suspension (front) Suspension (rear) Tyre (front) Tyre (rear) Brake (front) Brake (rear) | 25° 2,184 mm (86.0 inches) 826 mm (32.5 inches) 1,280 mm (50.4 inches) 1,486 mm (58.5 inches) 970 mm (38.2 inches) 325 mm (12.8 inches) 103.9 kg (229.0 pounds) 7.57 litres (2.00 gallons) Team Yamaha Blue KYB Speed-Sensitive System inverted fork; fully adjustable, 11.8-in travel KYB single shock; fully adjustable, 12.4-in travel 90/90-21 Dunlop AT81F 110/100-18 Dunlop AT81 Single hydraulic 250mm discs, twin piston calipers Single hydrarulic 245mm disc, single piston caliper |
| Frame Grips Handlebars Stem Forks Bars Headset Cranks Sprocket BB Gearing Chain Pedals Seat Rims Spokes Hub (front) Hub (rear) Brakes (rear) Brake Lever Bottom Bracket Tyres Wight | 100% hi-ten Steel Mission Micro Cobra high-tensil8.25 rise, 28.5" wide, 12⁰ upsweep, 1⁰ backsweep Mission Frontload, 30mm reach Kink Lance, 4130 CrMo including steerer, tapered fork legs Kink Puma CC 5” rise, 100% hi-ten Steel Standard 1 1/8″ threadless Mission Weider combo Mission X7 20H 14 gauge with brass nipples Mission unsealed, 3/8″ axle Mission unsealed, 3/8″ axle Innova 12x2.25″ front and rear 5.24kg/11lb 9oz |
| Frame Grips Handlebars Stem Forks Bars Headset Cranks Sprocket BB Gearing Chain Pedals Seat Rims Spokes Hub (front) Hub (rear) Brakes (rear) Brake Lever Bottom Bracket Tyres Wight | Blank 4130 TriMoly, removable brake hardware Blank Mushroom style flangeless Blank Compound, 9" rise Blank Compound high rise, top load, 55mm length Blank Compound 2+, tapered, CrMo steerer 1 1/8" Internal, sealed Blank ICS V2 (internal clamp system), 3-piece, 4130 CrMo Blank ‘WTF’ 25T, Steel KMC Z410, black painted Blank Slim Plastic Blank Newspaper Print, Pivotal with Pivotal seatpost Blank 40mm Compound V2, 20", 36H, Aluminium 14 gauge with brass nipples 10mm, Fully sealed bearings Fully sealed, 4 cartridge bearings, 9T cassette Rear 990 style U-brake, removable lugs Blank Hinged, Aluminium Mid, 19mm GMD Paint splat, 20"x2.4" front and rear 12.6kg |
| Frame Grips Handlebars Stem Forks Bars Headset Cranks Sprocket BB Gearing Chain Pedals Seat Rims Spokes Hub (front) Hub (rear) Brakes (rear) Brake Lever Bottom Bracket Tyres Wight | Blank 1020 Hi-Tensile Steel Blank Mushroom style flangeless Blank Compound 8" rise Blank Compound, top load, 55mm length Blank Compound, tapered Integrated 45°x45° sealed cartridge bearing 3-piece, 4130 CrMo Blank ‘WTF’ 25T, Steel Mid, sealed bearings KMC Z410 Plastic freestyle Blank Combo 20", 36H, Aluminium 14 gauge with brass nipples 10mm Open bearing Fully sealed, 4 cartridge bearings, 9T cassette Rear 990 style U-brake Resin/Aluminium combo USA 20"x2.3" front and rear 12.2kg |
| Frame Grips Handlebars Stem Forks Bars Headset Cranks Sprocket BB Gearing Chain Pedals Seat Rims Spokes Hub (front) Hub (rear) Brakes Brake Lever Bottom Bracket Tyres Wight | Trimoly, 20.75" Stranger Quan Hi-Ten, 8.75" Stranger top load Javelin High-Tensile Steel, tapered legs, 3/8" dropouts, 28mm rake Stranger Level CrMo Crank w/ 19mm spindle Primo JJ 990 w/ straight cable and removable mounts 20x2.4" Primo V-Monster front and rear |
| Frame Grips Handlebars Stem Forks Bars Headset Cranks Sprocket BB Gearing Chain Pedals Seat Rims Spokes Hub (front) Hub (rear) Brakes Brake Lever Bottom Bracket Tyres Wight | Colony Inception full CrMo, 18″ top tube, extra wide tyre clearance Colony Much Room Cobra high-tensil8.25 rise, 28.5" wide, 12⁰ upsweep, 1⁰ backsweep Colony forged top load alloy, 45mm reach Colony Inception CrMo, tapered legs with 1-piece CNC steerer tube Colony full CrMo, 7.9″ rise, 26″ wide Integrated Colony CrMo tubular, tapered 8-spline, 152mm Colony Endeavour alloy 25T Mid, sealed bearings KMC Colony Fantastic Plastic Colony Have Fun fat seat/post combo Colony 18″ double wall alloy, 36H Black steel Colony alloy female axle, fully sealed bearings, 36H low flange Colony alloy cassette, fully sealed bearings with 9T driver, 36H Alloy 990 style (rear) with clear pads Forged aluminium lever Sealed Mid 19mm 18×2.0″ front and rear 10kg |
| Frame Grips Handlebars Stem Forks Bars Headset Cranks Sprocket BB Gearing Chain Pedals Seat Rims Spokes Hub (front) Hub (rear) Brakes (rear) Brake Lever Bottom Bracket Tyres Wight | 6061 Alloy w/integrated Headset, Euro BB, 3D dropouts DK Tsuka lock-on 100% CrMo, 8.5"x28.25", 7°back, 3°up; 2pc design w/welded X-bar CNC alloy top load 1-1/8" 50mm DK RTV2 taper and butted CrMo w/alloy 20mm axle 45/45 integrated sealed cartridge bearings 175mm 2pc forged alloy 44t alloy 4-bolt KMC K-810 3/32 Silver DK PC platform Sun Envy Lite DBL wall 36H alloy 14G stainless black Sealed w/20mm axle Sealed w/20mm axle Promax Linear w/Green Airflow pads Promax V Point w/grip lock Euro integrated external Maxxis DTH 20x1.75/20x1.95 front and rear |
| Engine Engine type Bore x Stroke Displacement Valves Compression ratio Max Power Max Torque Fuel system Transmission Final drive Clutch Ignition type Starting system Lubrication Exhaust system Spark plug Battery Gear ratios | Liquid cooled, single cylinder, four-stroke, DOHC 77.0mm x 53.6mm 250cc 4 titanium valves per cylinder 13.5:1 Keihin fuel injection, 44mm Wide-ratio constant-mesh 6-speed O-ring chain Multi-plate wet Transistor Controlled Ignition Electric starter Wet sump 1st: 2nd: 3rd: 4th: 5th: 6th: |
| Dimensions Frame type Rake/trail Overall length Overall width Overall height Wheelbase Seat height Ground clearance Weight Fuel capacity Color Suspension (front) Suspension (rear) Tyre (front) Tyre (rear) Brake (front) Brake (rear) | 25° 2,164 mm (85.2 inches) 826 mm (32.5 inches) 1,280 mm (50.4 inches) 1,466 mm (57.7 inches) 965 mm (38.0 inches) 325 mm (12.8 inches) 112.9 kg (249.0 pounds) 7.57 litres (2.00 gallons) Team Yamaha Blue KYB Speed-Sensitive System KYB Fully adjustable single shock 90/90-21 Dunlop AT81F 110/100-18 Dunlop AT81 Single hydraulic 250mm discs, twin piston calipers Single hydrarulic 245mm disc, single piston caliper |
| Engine Engine type Bore x Stroke Displacement Valves Compression ratio Max Power Max Torque Fuel system Transmission Final drive Clutch Ignition type Starting system Lubrication Exhaust system Spark plug Battery Gear ratios | Liquid cooled, single cylinder, four-stroke, DOHC 77.0 x 53.6 mm (3.0 x 2.1 inches) 252cc 13.5:1 Yamaha Fuel Injection (YFI), Keihin 44mm Constant-mesh 5-speed Chain Multi-plate wet Transistor Controlled Ignition Kick starter Wet sump 1st: 2nd: 3rd: 4th: 5th: |
| Dimensions Frame type Rake/trail Overall length Overall width Overall height Wheelbase Seat height Ground clearance Weight Fuel capacity Color Suspension (front) Suspension (rear) Tyre (front) Tyre (rear) Brake (front) Brake (rear) | Aluminum, semi double cradle 28° 2,164 mm (85.2 inches) 826 mm (32.5 inches) 1,280 mm (50.4 inches) 1,476 mm (58.1 inches) 965 mm (38.0 inches) 325 mm (12.8 inches) 105 kg 6.06 litres (1.60 gallons) Team Yamaha Blue/White, 60th Anniversary Yellow Upside-down telescopic fork Fully adjustable single shock 80/100-R21 100/90-R19 Single hydraulic 250mm discs, twin piston calipers Single hydrarulic 245mm disc, single piston caliper |
| Engine Engine type Bore x Stroke Displacement Valves Compression ratio Max Power Max Torque Fuel system Transmission Final drive Clutch Ignition type Starting system Lubrication Exhaust system Spark plug Battery Gear ratios | Liquid cooled, single cylinder, four-stroke, DOHC 77.0 x 53.6 mm (3.0 x 2.1 inches) 252cc 13.5:1 Yamaha Fuel Injection (YFI), Keihin 44mm Constant-mesh 5-speed Chain Multi-plate wet Transistor Controlled Ignition Kick starter Wet sump 1st: 2nd: 3rd: 4th: 5th: |
| Dimensions Frame type Rake/trail Overall length Overall width Overall height Wheelbase Seat height Ground clearance Weight Fuel capacity Color Suspension (front) Suspension (rear) Tyre (front) Tyre (rear) Brake (front) Brake (rear) | Aluminum Bilateral Beam frame 28° 2,164 mm (85.2 inches) 826 mm (32.5 inches) 1,280 mm (50.4 inches) 1,476 mm (58.1 inches) 965 mm (38.0 inches) 325 mm (12.8 inches) 104.8 kg 6.06 litres (1.60 gallons) Team Yamaha Blue/White, 60th Anniversary Yellow KYB Speed-Sensitive System, inverted fork: fully adjustable KYB Fully adjustable single shock 80/100-R21 100/90-R19 Single hydraulic 250mm discs, twin piston calipers Single hydrarulic 245mm disc, single piston caliper |
| Engine Engine type Bore x Stroke Displacement Valves Compression ratio Max Power Max Torque Fuel system Transmission Final drive Clutch Ignition type Starting system Lubrication Exhaust system Spark plug Battery Gear ratios | Liquid cooled, single cylinder, two-stroke, reed-valve inducted 66.4 x 72.0 mm (2.6 x 2.8 inches) 249cc 10.6:1 Carburettor. Keihin PWK38S Constant-mesh 5-speed Chain Multi-plate wet CDI Electric starter Wet sump 1st: 2nd: 3rd: 4th: 5th: |
| Dimensions Frame type Rake/trail Overall length Overall width Overall height Wheelbase Seat height Ground clearance Weight Fuel capacity Color Suspension (front) Suspension (rear) Tyre (front) Tyre (rear) Brake (front) Brake (rear) | Semi-double cradle aluminium 26° 2,147 mm (84.5 inches) 827 mm (32.6 inches) 1,299 mm (51.1 inches) 1,481 mm (58.3 inches) 976 mm (38.4 inches) 367 mm (14.4 inches) 103 kg 8.00 litres (2.11 gallons) Team Yamaha Blue/white 48mm fork, separate air/oil function fork Monocross rear suspension system 80/100-R21 110/90-R19 Dual hydraulic 250mm discs, twin piston calipers Single hydrarulic 245mm disc, single piston caliper |
| Frame Grips Handlebars Stem Forks Bars Headset Cranks Sprocket BB Gearing Chain Pedals Seat Rims Spokes Hub (front) Hub (rear) Brakes Brake Lever Bottom Bracket Tyres Wight | 100% CrMo, 21" top tube Ricany x ODI grips Cult Salvation V3, forged alloy, top load 100%CrMo Full CrMo, 4-piece Integrated 175mm heat treated CrMo 3-piece Eastern Phorcys, cold hard steel, 25T 25Tx9T Cult 410 Cult nylon Cult Pivotal Double wall front and rear 14 gauge with brass nipples Fully sealed, female axle Fully sealed cassette hub, 14mm axle 990 U-Brakes (removable) Forged aluminium lever Sealed Mid BB Dehart 20"x2.40" slick front and rear |
| Frame Grips Handlebars Stem Forks Bars Headset Cranks Sprocket BB Gearing Chain Pedals Seat Rims Spokes Hub (front) Hub (rear) Brakes (rear) Brake Lever Bottom Bracket Tyres Wight | Full 1020 hi-ten Radio "AM” grips Radio AM 20 bar, 1020 hi-ten, Width 28.75"; Rise 8.6"; Upsweep 2° Salt "AM" top loading stem, 50mm reach Radio "Rookie" 1020 hi-ten fork, CrMo steerer FSA 1 1/8" "A-headset", loose ball Radio "Rookie" tubular 3-piece crank, CrMo, 165mm, 8-spline Radio "AM" steel 30T USA size, loose ball Salt"AM" chain, 510h type Salt “Slim” nylon/fibreglass Radio “Rookie” 20" rim, straight single wall, 36H 14 gauge with brass nipples Radio "Rookie" loose ball steel hub, 3/8" axle, 36H Radio "Rookie" loose ball steel hub, 3/8" axle, 36H Radio "AM" alloy U-brake-rear Radio “Junior” alloy brake lever Sealed Mid BB Kenda "Kontact", 20"x2.25” front & rear 11.89kg/26.12lb |
| Engine Engine type Bore x Stroke Displacement Valves Compression ratio Max Power Max Torque Fuel system Transmission Final drive Clutch Ignition type Starting system Lubrication Exhaust system Spark plug Battery Gear ratios | Liquid cooled, single cylinder, two-stroke, Reed-valve-inducted 54.0 x 54.5 mm (2.1 x 2.1 inches) 124cc 2 valves per cylinder 8.6:1 Carburettor. Mikuni TMX 38 6-speed Chain CDI Kick starter 1st: 2nd: 3rd: 4th: 5th: 6th: |
| Dimensions Frame type Rake/trail Overall length Overall width Overall height Wheelbase Seat height Ground clearance Weight Fuel capacity Color Suspension (front) Suspension (rear) Tyre (front) Tyre (rear) Brake (front) Brake (rear) | Aluminum 28° 2,136 mm (84.1 inches) 828 mm (32.6 inches) 1,295 mm (51.0 inches) 1,443 mm (56.8 inches) 975 mm (38.4 inches) 366 mm (14.4 inches) 94.8 kg 7.95 litres Team Yamaha Blue/White Speed-sensitive system inverted fork Fully adjustable single shock 80/100-R21 100/90-R19 Single hydraulic 250mm discs, twin piston calipers Single hydrarulic 245mm disc, single piston caliper |
| Engine Engine type Bore x Stroke Displacement Valves Compression ratio Max Power Max Torque Fuel system Transmission Final drive Clutch Ignition type Starting system Lubrication Exhaust system Spark plug Battery Gear ratios | Liquid cooled, single cylinder, four-stroke, DOHC 95.0 x 63.4 mm (3.7 x 2.5 inches) 449cc 5 valves per cylinder 11.8:1 Fuel Injection 42 mm EHS with ISC 5-speed Chain Slipper clutch Transistor Controlled Ignition Electric starter Dry sump 1st: 2nd: 3rd: 4th: 5th: |
| Dimensions Frame type Rake/trail Overall length Overall width Overall height Wheelbase Seat height Ground clearance Weight Fuel capacity Color Suspension (front) Suspension (rear) Tyre (front) Tyre (rear) Brake (front) Brake (rear) | Aluminum and steel 25° 1,795 mm (70.7 inches) 1,240 mm (48.8 inches) 1,065 mm (41.9 inches) 1,270 mm (50.0 inches) 810 mm (31.9 inches) 115 mm (4.5 inches) 184 kg 10 litres Team Yamaha Blue/White Independent double wishbone, 3-way adjustable damper Aluminium swingarm, threaded preload coil-over springs 21/7-R10 20/10-R9 Dual hydraulic discs with twin piston calipers Single disc with single piston caliper |
| Frame Grips Handlebars Stem Forks Bars Headset Cranks Sprocket BB Gearing Chain Pedals Seat Rims Spokes Hub (front) Hub (rear) Brakes (rear) Brake Lever Bottom Bracket Tyres Wight | Nagas High-Tensile Steel CrMo downtube, top tube and chainstays, 20.75″ top tube, 13.25" chainstay Eastern Riblet grips High-Tensile Steel 8.75" rise, 29" wide, 12⁰ upsweep, 1⁰ backsweep Forged aluminium top load stem Nagas full CrMo, tapered legs, 3/8" dropouts, 28mm rake Integrated 45°x45° sealed cartridge bearing 3-Piece, tubular heat-treated CrMo, pinch bolt with 8-splined spindle 170mm arm length Eastern Phorcys, CrMo, 25T Mid, sealed bearings KMC Z510 1/2"x1/8" Odyssey Twisted PC pedal with 9/16" CrMo axle 20″ 36H double wall aluminium rims 14 gauge with brass nipples Sealed bearings, forged aluminium shell, 36H, 3/8" CrMo axle Sealed bearings, forged aluminium shell, 36H, CrMo axle, 9T driver U-Brake, forged aluminium, wide body, clear brake pads Forged aluminium lever Sealed Mid BB Eastern Squealer 20"x2.4" front and rear 11.61kg/25.6lbs |
| Frame Grips Handlebars Stem Forks Bars Headset Cranks Sprocket BB Gearing Chain Pedals Seat Rims Spokes Hub (front) Hub (rear) Brakes Brake Lever Bottom Bracket Tyres Wight | 4130 CrMo downtube, 1020 Hi-Ten Steel WeThePeople "Arrow 146" Cobra high-tensil8.25 rise, 28.5" wide, 12⁰ upsweep, 1⁰ backsweep Salt "Pro" top loading stem, 50mm reach Salt AM 20” fork, 1020 Hi-Ten Steel, CrMo steerer, 28mm offset SaltPlus "Curse 20" bar, 1020 Hi-Ten Steel Salt "Pro" integrated, sealed bearing Salt "Rookie” tubular 3-piece crank, CrMo, 165mm, 8 Spline Salt "AM” steel, 25T sprocket Salt "AM" chain, 510H type Eclat “Surge” nylon/fiberglass WeThePeople "Curse 20” pivotal seat Salt "Fraction” rim, straight single wall, 36h 14 gauge with brass nipples Salt "AM” alloy hub, loose ball, male 3/8" axle, 36H Salt "AM” cassette hub, full sealed, 9T, 14mm axle, 36H SaltPlus "Geo XL" alloy u-brake rear Salt "AM” alloy brake lever Salt "Mid” 19mm, press fit, sealed bearing Salt "Tracer” 2.35" front and rear |
| Frame Grips Handlebars Stem Forks Bars Headset Cranks Sprocket BB Gearing Chain Pedals Seat Rims Spokes Hub (front) Hub (rear) Brakes Brake Lever Bottom Bracket Tyres Wight | 1020 hi-tensile steel, welded brake mounts, 1 1/8" head tube, embossed logo, top tube gusset United Jimmy Rushmore signature grips with United bar ends 1020hi-tensile steel, larger radius bends, 9" x 28.5", 2.5° upsweep United 50mm reach top load Tapered hi-tensile steel, CNC steerer tube, integrated bearing race United 1 1/8" integrated 3-piece tubular CrMo, 8-spline, 170mm printed united logo United solid, 25T United supreme X410 United Alex Valentino signature pedals, plastic Alloy 36h, single wall 14 gauge with brass nipples 36H Alloy, sealed bearing, 10mm axle 36h sealed cassette hub with 14mm axle, sealed bearing 9T driver 990 U-Brake Alloy United sealed bearing mid United Direct 20"x2.3" front and rear 11.29kg/24.9lbs |
| Engine Engine type Bore x Stroke Displacement Valves Compression ratio Max Power Max Torque Fuel system Transmission Final drive Clutch Ignition type Starting system Lubrication Exhaust system Spark plug Battery Gear ratios | Liquid cooled, single cylinder, four-stroke, DOHC 95.0 x 63.4 mm (3.7 x 2.5 inches) 449cc 5 valves per cylinder 11.8:1 Fuel Injection 42 mm EHS with ISC 5-speed Chain Slipper clutch Transistor Controlled Ignition Electric starter Dry sump 1st: 2nd: 3rd: 4th: 5th: |
| Dimensions Frame type Rake/trail Overall length Overall width Overall height Wheelbase Seat height Ground clearance Weight Fuel capacity Color Suspension (front) Suspension (rear) Tyre (front) Tyre (rear) Brake (front) Brake (rear) | Aluminum and steel 25° 1,795 mm (70.7 inches) 1,240 mm (48.8 inches) 1,065 mm (41.9 inches) 1,270 mm (50.0 inches) 810 mm (31.9 inches) 115 mm (4.5 inches) 184 kg 10 litres Team Yamaha Blue/White Independent double wishbone, 3-way adjustable damper Aluminium swingarm, threaded preload coil-over springs 21/7-R10 20/10-R9 Dual hydraulic discs with twin piston calipers Single disc with single piston caliper |
| Engine Engine type Bore x Stroke Displacement Valves Compression ratio Max Power Max Torque Fuel system Transmission Final drive Clutch Ignition type Starting system Lubrication Exhaust system Spark plug Battery Gear ratios | Air cooled, single cylinder, four-stroke, Single Overhead Cams 47.0 x 51.0 mm (1.9 x 2.0 inches) 88cc 2 valves per cylinder 10.2:1 113.45 HP (82.8 kW) @ 10000 rpm 87.50 Nm (8.9 kgf-m or 64.5 ft.lbs) @ 8900 rpm Carburettor. TK SVR 22 mm Automatic Chain Multi-plate wet DC-CDI Electric starter Wet sump |
| Dimensions Frame type Rake/trail Overall length Overall width Overall height Wheelbase Seat height Ground clearance Weight Fuel capacity Color Suspension (front) Suspension (rear) Tyre (front) Tyre (rear) Brake (front) Brake (rear) | 1,490 mm (58.7 inches) 885 mm (34.8 inches) 910 mm (35.8 inches) 1,010 mm (39.8 inches) 654 mm (25.7 inches) 100 mm (3.9 inches) 120 kg 4.8 litres Blue/white Independent double wishbone Swingarm 18/7-R8 18/9-R8 Expanding brake (drum brake) Expanding brake (drum brake) |
| Engine Engine type Bore x Stroke Displacement Valves Compression ratio Max Power Max Torque Fuel system Transmission Final drive Clutch Ignition type Starting system Lubrication Exhaust system Spark plug Battery Gear ratios | Liquid cooled, single cylinder, four-stroke, SOHC 102.0 x 84.0 mm (4.0 x 3.3 inches) 686cc 4 valves per cylinder 10.0:1 Electronic Fuel Injection, single throttle body, Mikuni 44EHS 5-speed Chain Multi-plate wet 32 bit, ECU Electric starter Dry sump 1st: 2nd: 3rd: 4th: 5th: |
| Dimensions Frame type Rake/trail Overall length Overall width Overall height Wheelbase Seat height Ground clearance Weight Fuel capacity Color Suspension (front) Suspension (rear) Tyre (front) Tyre (rear) Brake (front) Brake (rear) | 1845 mm (72.6 inches) 1155 mm (45.5 inches) 1115 mm (43.9 inches) 1280 mm (50.4 inches) 830 mm (32.7 inches) 240 mm (9.4 inches) 192 kg 11 litres Yellow Independent double wishbone, twin tube gas shock Cast aluminium swingarm, piggyback gas pressure shock, 22/7-R10 20/10-R9 Dual hydraulic discs, twin piston calipers Single hydrarulic disc, twinpiston caliper |
| Engine Engine type Bore x Stroke Displacement Valves Compression ratio Max Power Max Torque Fuel system Transmission Final drive Clutch Ignition type Starting system Lubrication Exhaust system Spark plug Battery Gear ratios | Liquid cooled, single cylinder, four-stroke, SOHC 102.0 x 84.0 mm (4.0 x 3.3 inches) 686cc 4 valves per cylinder 10.0:1 Electronic Fuel Injection, single throttle body, Mikuni 44EHS 5-speed Chain Multi-plate wet 32 bit, ECU Electric starter Dry sump 1st: 2nd: 3rd: 4th: 5th: |
| Dimensions Frame type Rake/trail Overall length Overall width Overall height Wheelbase Seat height Ground clearance Weight Fuel capacity Color Suspension (front) Suspension (rear) Tyre (front) Tyre (rear) Brake (front) Brake (rear) | Diamond 25° 1,845 mm (72.6 inches) 1,155 mm (45.5 inches) 1,115 mm (43.9 inches) 1,280 mm (50.4 inches) 830 mm (32.7 inches) 240 mm (9.4 inches) 192 kg 11 litres Blue/white Independent double wishbone, twin tube gas shock Cast aluminium swingarm, piggyback gas pressure shock, 22/7-R10 20/10-R9 Dual hydraulic discs, twin piston calipers Single hydrarulic disc, twinpiston caliper |
| Frame Grips Handlebars Stem Forks Bars Headset Cranks Sprocket BB Gearing Chain Pedals Seat Rims Spokes Hub (front) Hub (rear) Brakes (rear) Brake Lever Bottom Bracket Tyres Wight | Talisman High-Tensile Steel with CrMo downtube and top tube, 20.5″ top tube, 13.25" chainstay Eastern Riblet grips Cobra High-Tensile 8.25"rise, 28.5"wide, 12⁰upsweep, 1⁰ backsweep Forged aluminium top load stem Talisman High-Tensile Steel, tapered legs, 3/8" dropouts, 28mm rake Integrated 45°x45° sealed cartridge bearing 3-Piece, tubular heat-treated CrMo, pinch bolt with 8-splined spindle, 170mm arm length Eastern Phorcys, cold hard steel, 25T Mid, sealed bearings KMC Z510 1/2"x1/8" Odyssey Twisted PC pedal with 9/16" CrMo axle 20″ 36H double wall aluminium rims 14 gauge with brass nipples Sealed bearings, forged aluminium shell, 36H, 3/8" CrMo axle Sealed bearings, forged aluminium shell, 36H, CrMo axle, 9T driver U-Brake, forged aluminium, wide body, clear brake pads Forged aluminium lever Sealed Mid BB Eastern Squealer 20"x2.4" front and rear 11.56kg/25.5lbs |
| Frame Grips Handlebars Stem Forks Bars Headset Cranks Sprocket BB Gearing Chain Pedals Seat Rims Spokes Hub (front) Hub (rear) Brakes Brake Lever Bottom Bracket Tyres Wight | 100% CrMo, S-Bend chainstays for bigger tyres Stolen Team Flanged, 165mm Saint 2-piece CrMo, 8.00″ rise Stolen Stratos 52mm 100% CrMo, tapered legs, one-piece steerer, compressor topcap Stolen Vortex Fiction Savage sealed integrated, 15mm alloy bearing cover 48 Spline, tubular CrMo arms, CrMo spindle, 175mm 6061AL, 25T Mid, sealed bearings Z-410, Black Stolen Thermalite, CrMo spindles Medium width seat/post combo 24″ Stolen Rampage 36H (double-wall) 14 gauge with brass nipples Stolen Rampage sealed 3/8″ axle Stolen Rampage sealed cassette, 14mm axle APSE U25 Alloy U-brake APSE alloy with hinged clamp Fiction Savage MID, 19mm Stolen Joint, 24x2.20″ front and rear 12.13kg/26.75lbs |
