Technical Specifications
2017 Aprilia RSV4 FW-GP
Image: https://ultimatemotorcycling.com/2016/12/20/aprilia-rsv4-fw-gp-250-hp-factory-works-motogp-bike/
2017 Aprilia RSV4 FW-GP
Engine Engine type Bore x Stroke Displacement Valves Compression ratio Max Power Max Torque Fuel system Transmission Final drive Clutch Ignition type Starting system Lubrication Exhaust system Spark plug Alternator Gear ratios | Liquid cooled, Longitudinal 65° V-4 cylinder, four stroke, DOHC 78.0 x 52.3 mm (3.1 x 2.1 inches) 999.6 ccm 4 valves per cylinder 12.5:1 Injection. Airbox with front dynamic air intakes 6-speed Chain Multi-disc oil-bath, with mechanical slipper system Magneti Marelli digital electronic ignition system Electric starter Wet sump lubrication system with oil radiator and two oil pumps |
Dimensions Frame type Rake/trail Overall length Overall width Overall height Wheelbase Seat height Ground clearance Weight Fuel capacity Color Suspension (front) Suspension (rear) Tyre (front) Tyre (rear) Brake (front) Brake (rear) | Twin-spar adjustable aluminium frame, with castings and pressings 24.5° 2,040 mm (80.3 inches) 735 mm (28.9 inches) 1,120 mm (44.1 inches) 1350 mm (53.1 inches) 840 mm (33.1 inches) 130 mm (5.1 inches) 120 kg 17.00 litres (4.49 gallons) Black/silver/red/green Ohlins Racing upside-down fork, 43-mm stanchions Twin sided aluminium swingarm. Ohlins piggyback shock absorber 120/70-ZR17 200/55-ZR17 Double floating stainless steel disc 323 mm disc with four-piston calipers Single floating calliper 220 mm disc with single-piston caliper |
