SpecificationsRagley Trig Bike 2021
Frame: Ragley Trig 4130 Chromoly (CrMo)
Fork: Ragley Carbon Disc Fork, 12mm x 100mm, Flat Mount
Headset: FSA NO.9M,1 1/8-1.5 Tapered
Compression Device: FSA TH-883-1 Compressor
Handlebar: Ragley Alloy, 31.8mm, 48cm-400mm Wide, 50cm-420mm Wide, 52/55/58cm-440mm Wide
Stem: Ragley, 31.8mm Clamp, 7 Degree Rise, 48 / 50cm:70mm, 52cm:80mm, 55 / 58cm:90mm
Bar Tape: Ragley Black cork cushion tape with bar end plug
Front Wheel: Nukeproof Neutron Hub, 12mm x 100mm, Sealed bearings, 32h, 6-bolt disc on a WTB ST i25 TCS 2.0 Rim 650b (taped for tubeless)
Rear Wheel: Nukeproof Neutron Hub, 36 points of engagement, 142mm x 12mm, Sealed bearings, 32h, 6-bolt disc on a WTB ST i25 TCS 2.0 Rim 650b (taped for tubeless)
Front Thru Axle Spec: Diameter: 12mm, Pitch:1.5, Length:120mm
Rear Thru Axle Spec: Diameter 12mm, Pitch 1.75, Axle Length 167mm, Thread Length: 20mm
Front Tyre: WTB Sendero 650b x 47c Tan Sidewall, Dual DNA Compound, Lightweight Tubeless Casing, TCS Aramid Bead
Rear Tyre: WTB Sendero 650b x 47c Tan Sidewall, Dual DNA Compound, Lightweight Tubeless Casing, TCS Aramid Bead
Chain: KMC 11 speed
Crankset: Shimano RX600, GRX 11-speed, 170mm, 40t
Bottom Bracket: Shimano Hollowtech II 73mm BSA
Front Brake: Shimano GRX RX600 lever with RX400 calliper, 160mm RT66 rotor, Resin pads with fin
Rear Brake: Shimano GRX RX600 lever with RX400 calliper, 160mm RT66 rotor, Resin pads with fin
Rear Derailleur: Shimano GRX RX812 11-Speed, Shadow Plus
Rear Shifter: Shimano RX600 11 speed
Drivetrain Cables: Shimano
Cassette: Shimano SLX M7000, 11-Speed, 11-13-15-17-19-21-24-28-32-37-42
Saddle: Ragley Tracker
Seatpost: Ragley 27.2mm x 400mm
Seat Screw: Ragley 29.8mm
