Specifications
2017 Kawasaki KX 100
Weight incl. oil, gas, etc: 71.0 kg (156.5 pounds)
Seat height: 871 mm (34.3 inches) If adjustable, lowest setting.
Overall height: 1151 mm (45.3 inches)
Overall length: 1910 mm (75.2 inches)
Overall width: 765 mm (30.1 inches)
Ground clearance: 381 mm (15.0 inches)
Wheelbase: 1290 mm (50.8 inches)
Fuel capacity: 5.68 litres (1.50 US gallons)
Frame type: High-tensile steel perimeter design with subframe member
Rake (fork angle): 29.0°
Trail: 109 mm (4.3 inches)
Front suspension: 36mm inverted telescopic cartridge fork with 18-way compression damping
Front wheel travel: 274 mm (10.8 inches)
Rear suspension: Uni-Trak single shock system with 4-way compression and 18-way rebound damping plus adjustable spring preload
Rear wheel travel: 274 mm (10.8 inches)
Front tire: 70/100-19
Rear tire: 90/100-16
Front brakes: Single disc
Rear brakes: Single disc
Displacement: 99.0 ccm (6.04 cubic inches)
Engine type: Single cylinder, two-stroke
Engine details: Reed valve
Compression: 9.6:1
Bore x stroke: 52.5 x 45.8 mm (2.1 x 1.8 inches)
Fuel system: Carburettor. Keihin PWK28
Ignition: CDI w/digital advance
Cooling system: Liquid
Gearbox: 6-speed
Transmission type,
final drive: Chain
