Kawasaki Ninja H2R (2017)


Specifications
2017 Kawasaki Ninja H2R
Weight incl. oil, gas, etc: 216.1 kg (476.3 pounds)
Seat height: 830 mm (32.7 inches) If adjustable, lowest setting.
Overall height: 1160 mm (45.7 inches)
Overall length: 2070 mm (81.5 inches)
Overall width: 850 mm (33.5 inches)
Ground clearance: 130 mm (5.1 inches)
Wheelbase: 1450 mm (57.1 inches)
Fuel capacity: 17.00 litres (4.49 US gallons)
Frame type: Trellis, high-tensile steel with Swingarm Mounting Plate
Rake (fork angle): 27.0°
Trail: 108 mm (4.3 inches)
Front suspension: 43 mm inverted fork with rebound and compression damping, spring preload adjustability and top-out springs
Front wheel travel: 120 mm (4.7 inches)
Rear suspension: Uni-Trak, Öhlins TTX36 gas-charged shock with piggyback reservoir, compression damping, rebound damping, preload adjustability and top-out spring
Rear wheel travel: 135 mm (5.3 inches)
Front tire: 120/70-R17
Rear tire: 190/65-R17
Front brakes: Double disc. Brembo. Floating discs. Opposed 4-piston caliper
Diameter: 330 mm (13.0 inches)
Rear brakes: Single disc. Brembo. Opposed 2-piston caliper
Diameter: 250 mm (9.8 inches)
Displacement: 998.0 ccm (60.90 cubic inches)
Engine type: In-line four, four-stroke
Engine details: Kawasaki supercharger intake system
Power: 310.0 HP (226.3 kW) @ 14000 RPM
Torque: 165.0 Nm (16.8 kgf-m or 121.7 ft.lbs) @ 12500 RPM
Compression: 8.3:1
Bore x stroke: 76.0 x 55.0 mm (3.0 x 2.2 inches)
Valves per cylinder: 4
Fuel system: Injection
Fuel control: Double Overhead Cams/Twin Cam (DOHC)
Ignition: Digital
Lubrication system: Forced lubrication, wet sump with oil cooler
Cooling system: Liquid
Gearbox: 6-speed
Transmission type,
final drive: Chain
Clutch: Wet multi-disc, manual
Driveline: Sealed chain
